150A/200A Type 2 DC Charging Socket

The 150A/200A Type 2 DC Charging Socket is a high-performance solution designed for new energy electric vehicles requiring fast and reliable DC charging. Compliant with the IEC 62196-3 standard, this CCS Combo 2 charging socket is engineered for seamless integration with DC charging gun heads and comes equipped with a durable 1-meter cable for flexible installation.

This charging socket is available in 80A, 150A, and 200A DC current ratings, supporting a working voltage of up to 600V DC. It features a robust safety insulation design on the pin head, effectively preventing accidental direct contact and enhancing user safety. The socket delivers superior protection performance with an IP55 rating, making it suitable for both indoor and outdoor environments.

Built for longevity, the Type 2 DC Charging Socket boasts a mechanical life of over 10,000 no-load plug cycles. Its electrical performance is outstanding, with insulation resistance greater than 200MΩ (DC1000V), a terminal temperature rise of less than 50K, and a withstand voltage of 3000V. The contact impedance is kept to a minimum at .5mΩ max, ensuring efficient and stable power transfer during every charging session.

Constructed from flame-retardant thermoplastic (UL94V- grade) and featuring copper alloy contact pins with a silver-plated surface and thermoplastic top, this socket is designed for durability and optimal conductivity. It operates reliably in ambient temperatures ranging from -30°C to +50°C, making it ideal for a wide range of climates and installation scenarios.

Technical Specifications:

• Standard: IEC 62196-3
• Rated DC current: 80A / 150A / 200A
• Working voltage: 600V DC
• Insulation resistance: >2000MΩ (DC1000V)
• Terminal temperature rise: <50K
• Withstand voltage: 3000V
• Contact impedance: .5mΩ max
• Mechanical life: >10,000 no-load plug cycles
• Protection level: IP55
• Shell material: Thermoplastic, flame retardant grade UL94V-
• Contact pin: Copper alloy, silver-plated + thermoplastic top
• Cable length: 1 meter
• Operating temperature: -30°C to +50°C

What’s in the Pack:

• 1x Type 2 DC Charging Socket (selected current rating)
• 1x 1-meter cable
• User manual

For step-by-step installation guidance, visit our Mobile Energy System Guide. To complete your EV charging setup, explore our Accessories Collection, where you’ll find compatible products and helpful resources. If you’re interested in flexible charging solutions, check out our Flexible Charging Kits, designed to work seamlessly with the 150A/200A Type 2 DC Charging Socket.

1.Working environment temperature: – 30 ℃~+50 ℃
