300W-700W MPPT Grid Tie Micro Inverter

The 300W–700W MPPT Grid Tie Micro Inverter is a compact, high-performance solution for converting solar DC power directly into AC for home or office use, while synchronizing seamlessly with the utility grid. Designed for optimal efficiency and reliability, this micro inverter features advanced MPPT (Maximum Power Point Tracking) technology, ensuring you get the most energy from your solar panels.

With a wide input voltage range (18–60V) and a recommended operating range of 18–42V (Vmp), this inverter is best paired with solar panels featuring a Vmp of 30–42V and a Voc of 38–60V. It is not recommended for use with 12V panels, as low sunlight may cause unstable operation. The inverter is built with durable aluminum alloy for superior heat dissipation and includes over-temperature protection—automatically reducing output or shutting down if temperatures become excessive, then restarting after cooling.

Installation is straightforward, and the inverter should be placed in a ventilated, dry, and cool location away from direct sunlight and rain. The package includes the grid tie inverter and a 30cm AC cable. In case of fuse damage, free replacement accessories and video instructions are provided for easy maintenance.

Technical Specifications

• Power Output: 300W–700W
• Input Voltage: 18–60V DC (start at 24V)
• Recommended Panel Vmp: 30–42V
• Recommended Panel Voc: 38–60V (do not exceed 60V)
• Output: Synchronized AC, grid tie
• MPPT: Yes
• Cooling: Aluminum alloy case for efficient heat dissipation
• Over-Temperature Protection: Yes
• Warranty: 1 year
• Package Includes: 1 × Grid Tie Inverter, 1 × 30cm AC Cable

Package Includes

• 1 × Grid Tie Micro Inverter (300W–700W MPPT)
• 1 × AC Cable (30cm)

For installation guides, technical support, and compatible accessories, visit our Solar Power Collection. Explore more micro inverters and solar solutions in our Renewable Energy Range.

Regarding the heating problem of the inverter:

this is normal phenomenon. All electronic devices generate heat during operation. The inverter uses aluminum alloy material. Metal can conduct heat better. The inverter also has over-temperature protection if the temperature is high. Then the inverter will automatically reduce the working output efficiency. Or stop working. After cooling down, restart. It is recommended to install the inverter in a ventilated, dry and cool place.

Install away from direct sunlight and direct rain exposure.(Ventilated, dry, cool)Package Include:

1XGrid Tie Inverter
1 x AC Cable 30CM
