Nema 11 Bipolar Stepper Motor, 1.8 Degrees, 28BYG

• Accurate positioning control with minimal positional error
• Precise control and adjustment of rotational speed
• Capabilities for CW/CCW adjustment, emergency stop, and locking functions
• Long service life

The Nema 11 Bipolar Stepper Motor, 1.8 Degrees, 28BYG comes complete with a driver. It has a size of 28x28x32mm and four wires, with a holding torque of 0.06 N.m.

Motor: 28mm x 28mm x 32mm

Shaft: 5mm x 15mm

Driver: 56mm x 94mm x 21mm

Motor Type: Bipolar Stepper

Step Angle: 1.8 degrees

Holding Torque: 0.06 Nm

Rated Current/Phase: 0.45 A

Phase Resistance: 5.6 ohms

Inductance: 4.2 mH, 20% (1 kHz)

Connection:

A+: Black

A: Green

B+: Red

B: Blue

Frame Size: 28 x 28 mm

Body Length: 32 mm

Shaft Diameter: 5 mm

Shaft Length: 15 mm

Number of Leads: 4

Lead Length: 300 mm

Weight: 110 g
