UFACTORY BIO Gripper

The UFACTORY BIO Gripper is an intelligent, collaborative robotic gripper engineered for advanced liquid handling and automation applications. Designed for rapid deployment and easy customization, this gripper features switchable and customizable fingertips, allowing for exceptional adaptability across a wide range of tasks. Its robust communication is powered by RS-485 with Modbus RTU protocol, ensuring reliable and efficient data exchange with your automation system.

The BIO Gripper provides programmable gripping specifications, including speed control, to meet diverse operational requirements. Real-time status and power indicators offer immediate feedback, while advanced drop and pick-up detection mechanisms ensure precise and secure object handling. The gripper’s modular design enables quick fingertip changes, maximizing flexibility for specialized applications.

With a stroke of 81 mm and a working range of 48–129 mm (with default fingers), the UFACTORY BIO Gripper delivers a maximum gripping force of 20 N. Its lightweight construction (816 g) and low power consumption make it ideal for integration with collaborative robots in laboratory, research, and industrial environments.

Technical Specifications

• Rated Supply Voltage: 24V DC
• Absolute Maximum Supply Voltage: 28V DC
• Static Power Consumption: .96 W
• Peak Current: 1.5 A
• Maximum Gripping Force: 20 N
• Stroke: 81 mm
• Working Range (default fingers): 48–129 mm
• Finger Type: Switchable, customizable
• Communication Mode: RS-485
• Communication Protocol: Modbus RTU
• Programmable Gripping Specification: Speed control
• Status Indication: Working status, power
• Feedback: Drop detection, pick-up detection
• Weight: 816 g

Package Includes

• 1 × UFACTORY BIO Gripper

For integration guides, technical support, and compatible accessories, visit our Automation Accessories Collection. Explore more advanced robotic solutions in our Robotics Range.
